NEWMEEN
High Speed Lab Refrigerated Centrifuge GTR116C
CENTRIFUGES
Product Overview
Introducing the High-Speed Table Refrigerated Centrifuge GTR116C—a cutting-edge laboratory instrument designed for accurate and efficient separation of samples across a variety of applications. With a combination of advanced technology, user-friendly interfaces, and reliable performance, the GTR116C is the perfect solution for laboratories engaged in molecular biology, biochemistry, and clinical research.
Key Specifications
- Model: GTR116C
- Maximum Speed: 16,500 RPM
- Maximum RCF (Relative Centrifugal Force): 21,615 × g
- Maximum Capacity: 12 x 5 ml tubes
- Timer: 1 second to 99 hours, 59 minutes, 59 seconds
- Revolutions per Minute Accuracy: ± 10 RPM
- Temperature Range: -20°C to 40°C
- Temperature Accuracy: ± 1.0°C
- Voltage: AC 220 ± 22V, 50Hz, 10A
- Power: 550W
- Noise Level: ≤ 60 dB (A)
- Size: 315 mm x 475 mm x 310 mm
- Net Weight: 38 kg
Design and Construction
The GTR116C centrifuge features a robust construction that ensures durability and reliability under varied laboratory conditions. The full steel inner cavity provides a protective cover, enhancing the safety of both the user and the equipment during operation. Its compact design makes this centrifuge suitable for table-top use, optimizing space in crowded laboratories.
Advanced Features
Automatic Rotor Identification
One of the standout features of the GTR116C is its automatic rotor identification. This technology enhances user safety and simplifies operation by automatically detecting the rotor type and adjusting the maximum speed limits accordingly. This feature prevents users from misusing the centrifuge with an incorrect rotor type, which could compromise sample integrity or damage the equipment.
Speed Limit Control
The centrifuge incorporates an intelligent speed limit control system. This mechanism ensures that the centrifuge operates within safe speed ranges, thereby mitigating risks associated with over-speed conditions. This feature is especially crucial for sensitive samples that could be affected by excessive centrifugal forces.
Safety Protections
Safety is paramount in laboratory operations. The GTR116C is equipped with several safety features:
- Overspeed Protection: Automatically shuts off the motor if the rotor exceeds the maximum speed limit.
- Overheat Protection: Prevents overheating during prolonged use, extending the lifespan of the device.
- Unbalance Protection: The centrifuge detects imbalance in the rotor and halts operation to prevent damage and ensure user safety.
Applications
The High-Speed Table Refrigerated Centrifuge GTR116C is suitable for a variety of applications, making it an invaluable tool in multiple research settings:
Precipitation Separation: Efficiently separates components in liquid samples by utilizing high centrifugal forces, enabling effective sedimentation of particles.
Nanometer Material Separation: Ideal for separating nanoscale materials used in research and development projects across various scientific fields.
Lotion Separation: Best for laboratories specializing in cosmetic formulation, where the separation of ingredients ensures product consistency and quality.
Cell Separation: Instrumental in biological research, particularly in cell culture studies where performance in handling delicate cell types is critical.
Protein Separation and Purification: Perfect for biochemists requiring high precision in protein extraction processes, critical for numerous applications in drug development and proteomics.
Biological Sample Separation: Excellent for separating blood, urine, and other biological samples, aiding in diagnosis and research in clinical laboratories.
Water Quality Detection: Useful in environmental laboratories for assessing water quality by separating contaminants from samples.
User-Friendly Interface
The GTR116C is designed for ease of use, featuring an intuitive interface that allows users to set parameters quickly. The digital display provides real-time monitoring of critical parameters, including speed, time, and temperature, enabling precise control over the centrifugation process.
Maintenance and Care
To ensure optimal performance and longevity of the GTR116C, regular maintenance is essential. Here are some best practices for users:
- Conduct routine inspection of rotor and accessories for any signs of wear or damage.
- Clean the centrifuge after each use, ensuring no residual samples are left that could contaminate future experiments.
- Periodically check the calibration of the temperature and speed settings to ensure accuracy.
- Follow the recommended service schedule set by the manufacturer for internal components.
Conclusion
The High-Speed Table Refrigerated Centrifuge GTR116C is an exceptional choice for laboratories looking to enhance their separation processes. With its impressive specifications, advanced safety features, and broad application range, it is set to meet the increasing demands of modern scientific research. Whether you are working in clinical, biological, or environmental settings, the GTR116C provides the reliability and performance required to achieve reproducible results. Make this powerhouse of technology a part of your laboratory setup, and experience the difference in your workflows and outcomes.
Ordering Information
For further inquiries, customization options, or to place an order for the High-Speed Table Refrigerated Centrifuge GTR116C, please contact our sales team directly. We also provide training resources and support services to ensure a seamless integration into your laboratory environment.
Final Remarks
Embrace the future of laboratory excellence with the GTR116C—a state-of-the-art centrifuge engineered for precision, safety, and efficiency. Whether you are in a fast-paced research lab or a clinical setup, the GTR116C is designed to deliver reliable performance that you can count on.
