NEWMEEN
Low Speed Refrigerated Centrifuge DDR6C Lab Floor type
CENTRIFUGES
Product Details for Floor Type Low Speed Refrigerated Centrifuge DDR6C
Introduction
The Floor Type Low Speed Refrigerated Centrifuge DDR6C is a cutting-edge laboratory instrument designed for various applications in biological sciences, chemistry, and other fields of scientific research. Its sophisticated engineering, combined with advanced technology, makes it an indispensable tool for researchers who demand high performance, efficiency, and reliability. The DDR6C is uniquely suited for centrifugation processes requiring precise temperature control and speed adjustment, ensuring optimal separation of samples in diverse laboratory settings.
Product Specifications
- Model: DDR6C
- Max Speed: 6500 rpm
- Max RCF: 6680 × g
- Max Capacity: 6 × 1000 ml
- Timer: 1 s to 99 h 59 min 59 s
- Revolutions/min Accuracy: ±10 r/min
- Temperature Range: -20℃ to 40℃
- Temperature Accuracy: ±1.0℃
- Input Voltage: AC 220 ± 22V; 50Hz; 15A
- Power Consumption: 3.2 KW
- Noise Level: ≤ 65 dB(A)
- Physical Dimensions: 905 × 755 × 1075 mm
- Net Weight: 325 kg
- Rotor Automatic Identification: Yes
Key Features
High Speed and RCF Performance:
- The DDR6C can reach a maximum speed of 6500 rpm, generating a maximum relative centrifugal force of 6680 × g. This capability ensures effective separation of samples, catering to a wide range of research applications where speed is paramount.
Versatile Capacity:
- With a maximum capacity of 6 × 1000 ml, this centrifuge allows for the processing of large volumes of samples in a single run, optimizing workflow efficiency in the laboratory.
Advanced Temperature Control:
- The centrifuge operates within a temperature range of -20℃ to 40℃, allowing for temperature-sensitive samples to be processed without degradation. With an accuracy of ±1.0℃, researchers can trust that their samples are maintained at the desired temperature throughout the centrifugation process.
User-Friendly Timer:
- The integrated timer can be set from a minimum of 1 second to a maximum of 99 hours, enabling automated operation and flexibility in experimental designs that require specific centrifugation durations.
Speed Control Options:
- The DDR6C features a user-selectable speed up/down mode, allowing researchers to customize the acceleration and deceleration profiles. This functionality helps to minimize sample disturbance and potential degradation during the centrifugation process.
RCF Calculation:
- The centrifuge is equipped with an auto-calculation feature that computes the relative centrifugal force based on the rotor speed and required parameters, enhancing usability and ensuring accurate results.
Ample Program Storage:
- Users can store up to 99 different centrifugation programs in the DDR6C's memory, facilitating quick access to frequently used settings. This large storage capability helps streamline laboratory operations and adapt to varied experiment requirements.
Safety Features:
- The centrifuge includes an electric door lock that automatically opens the chamber door once the centrifugation cycle is concluded. This ensures user safety by preventing accidental opening during operation and maintains sample integrity.
Low Noise Operation:
- With a noise level of ≤ 65 dB(A), the DDR6C operates quietly, making it suitable for use in environments where noise minimization is crucial, such as in clinical or research laboratories.
Durable Construction:
- Built with high-quality materials, the DDR6C is designed for longevity and reliability even under regular use. Its robust construction reduces operational wear and extends the lifespan of the equipment.
High Speed and RCF Performance:
- The DDR6C can reach a maximum speed of 6500 rpm, generating a maximum relative centrifugal force of 6680 × g. This capability ensures effective separation of samples, catering to a wide range of research applications where speed is paramount.
Versatile Capacity:
- With a maximum capacity of 6 × 1000 ml, this centrifuge allows for the processing of large volumes of samples in a single run, optimizing workflow efficiency in the laboratory.
Advanced Temperature Control:
- The centrifuge operates within a temperature range of -20℃ to 40℃, allowing for temperature-sensitive samples to be processed without degradation. With an accuracy of ±1.0℃, researchers can trust that their samples are maintained at the desired temperature throughout the centrifugation process.
User-Friendly Timer:
- The integrated timer can be set from a minimum of 1 second to a maximum of 99 hours, enabling automated operation and flexibility in experimental designs that require specific centrifugation durations.
Speed Control Options:
- The DDR6C features a user-selectable speed up/down mode, allowing researchers to customize the acceleration and deceleration profiles. This functionality helps to minimize sample disturbance and potential degradation during the centrifugation process.
RCF Calculation:
- The centrifuge is equipped with an auto-calculation feature that computes the relative centrifugal force based on the rotor speed and required parameters, enhancing usability and ensuring accurate results.
Ample Program Storage:
- Users can store up to 99 different centrifugation programs in the DDR6C's memory, facilitating quick access to frequently used settings. This large storage capability helps streamline laboratory operations and adapt to varied experiment requirements.
Safety Features:
- The centrifuge includes an electric door lock that automatically opens the chamber door once the centrifugation cycle is concluded. This ensures user safety by preventing accidental opening during operation and maintains sample integrity.
Low Noise Operation:
- With a noise level of ≤ 65 dB(A), the DDR6C operates quietly, making it suitable for use in environments where noise minimization is crucial, such as in clinical or research laboratories.
Durable Construction:
- Built with high-quality materials, the DDR6C is designed for longevity and reliability even under regular use. Its robust construction reduces operational wear and extends the lifespan of the equipment.
Applicable Scenarios
The DDR6C is suitable for a wide variety of applications in different fields, including:
Biological Research:
- Extraction of cellular components, purification of nucleic acids, and protein analysis.
Clinical Laboratories:
- Separation of blood components, preparation of serum, and testing of biochemical markers.
Chemical Engineering:
- Processes requiring particle separation from liquids, clarification of suspensions, and extraction in organic chemistry.
Environmental Studies:
- Analyzing soil and water samples for particulate matter and pollutants.
Advantages
Efficient and Fast Processing:
- The DDR6C's ability to quickly reach high speeds and RCF levels facilitates rapid and efficient processing of samples, saving valuable time in research.
Customizability:
- The extensive programmability and operational flexibility make the centrifuge adaptable to specific experimental protocols, providing enhanced control over conditions based on research needs.
Reliability for Critical Experiments:
- The precise temperature control and speed calculate features ensure that samples are processed under optimal conditions, leading to reliable and reproducible results.
Enhanced Laboratory Workflow:
- With features such as shortcut keys for program grouping and automated calculations, the DDR6C minimizes setup time and maximizes operational efficiency within the lab.
Efficient and Fast Processing:
- The DDR6C's ability to quickly reach high speeds and RCF levels facilitates rapid and efficient processing of samples, saving valuable time in research.
Customizability:
- The extensive programmability and operational flexibility make the centrifuge adaptable to specific experimental protocols, providing enhanced control over conditions based on research needs.
Reliability for Critical Experiments:
- The precise temperature control and speed calculate features ensure that samples are processed under optimal conditions, leading to reliable and reproducible results.
Enhanced Laboratory Workflow:
- With features such as shortcut keys for program grouping and automated calculations, the DDR6C minimizes setup time and maximizes operational efficiency within the lab.
Conclusion
In summary, the Floor Type Low Speed Refrigerated Centrifuge DDR6C is a high-performance, versatile instrument that provides advanced features tailored for the rigorous demands of scientific research. Its combination of speed, capacity, and safety ensures that it stands out as a vital asset in laboratories focused on biological, chemical, and environmental applications. The DDR6C not only enhances the research process with its innovative technology but also reinforces the commitment to delivering accurate and reliable scientific results. Investing in the DDR6C means choosing a tool that empowers researchers to achieve their goals with confidence and ease.
